Impact milling cutters

These tools are a radical innovation for milling-off deposits in pipes. The enz® impact milling cutters are designed to remove the most stubborn deposits like concrete, injection cement, mineral deposits etc. They work with a percussion system of 600-3000 impulses per minute and up to 12 tons of impact force. Please ask for special equipment for plastic deposits! When using the pull rod (drawing device) the cutters can be driven with half the water quantity (from 200 mm).

Characteristics

superior performance compared to other cutters
extended tooth life
easy handling
low maintenance cost
proven design

All impact milling cutters can be operated without impacts.

Impact milling cutters 1" - 1 1/4"

Item number	Item name
14.400	Impact drilling-cutter 400mm complete	1", 1 1/4"	400	300	3 x M10	3 x M10	375 x 710	89.00	150
14.450	Impact drilling-cutter 450mm complete	1", 1 1/4"	450	400	3 x M10	3 x M10	425 x 710	107.00	150
14.500	Impact drilling-cutter 500mm complete	1", 1 1/4"	500	450	3 x M10	3 x M10	475 x 710	111.00	150
14.600	Impact drilling-cutter 600mm complete	1", 1 1/4"	600	500	3 x M10	3 x M10	575 x 710	120.00	150

Accessory and wearing parts impact milling cutters

Item number		Item name
0014.30011	Extension for the shaft of IM 300	Extension for the shaft of IM 300		0.45
0014.3008	Additional weight for impact milling cutter	Additional weight for impact milling cutter	300 - 600	6.75
14.2215ZS	Pull-rod M22x1.5x200 mm	Pull-rod M22x1.5x200 mm	200 - 600	1.00
14.400K	Impact milling cutter head 400 mm	Impact milling cutter head 400 mm	400	12.00
14.400NA	Hub for impact drilling-cutter 400 mm	Hub for impact drilling-cutter 400 mm	400 - 450	12.00
14.450K	Impact milling cutter head 450 mm	Impact milling cutter head 450 mm	450	13.50
14.450KU	Adapter plates for skids 450-600 mm	Adapter plates for skids 450-600 mm	450 - 600	16.00
14.500K	Impact milling-cutter head 500 mm	Impact milling-cutter head 500 mm	500	17.00
14.500NA	Hub for impact drilling-cutter 500 mm	Hub for impact drilling-cutter 500 mm	500	12.70
14.600K	Impact milling-cutter head 600 mm	Impact milling-cutter head 600 mm	600	19.00
14.600NA	Hub for impact drilling-cutter 600 mm	Hub for impact drilling-cutter 600 mm	600	12.70
14.K05	Cam plate 5mm per pc. with screws	Cam plate 5mm per pc. with screws	200 - 600	0.20
15.ZKB	Center cap with bored hole	Center cap with bored hole		0.60
