Impact milling cutters

These tools are a radical innovation for milling-off deposits in pipes. The enz® impact milling cutters are designed to remove the most stubborn deposits like concrete, injection cement, mineral deposits etc. They work with a percussion system of 600-3000 impulses per minute and up to 12 tons of impact force. When using the pull rod (drawing device) the cutters can be driven with half the water quantity (from 200 mm).

Characteristics

superior performance compared to other cutters
extended tooth life
easy handling
low maintenance cost
proven design

All impact milling cutters can be operated without impact.

Impact milling cutters 500 - 600 (19.7" - 23.6")

Item number	Item name
14.500	Percussion milling head 19.7" complete	1 1/4"	20	119	3 x M10	3 x M10	18.7 x 28.0	244.71	2,100
14.600	Percussion milling cutter 23.6" complete	1 1/4"	24	132	3 x M10	3 x M10	22.6 x 28.0	264.56	2,100

Accessory and wearing parts impact milling cutters

Item number		Item name
0010.3809	Kufenrolle Ø Ø 2.36"	Kufenrolle Ø Ø 2.36"		0.93
0010.38091	Skid roller for skid centre Ø 1.57"	Skid roller for skid centre Ø 1.57"
0014.30011	Shaft extension	Shaft extension		0.99
0014.3003	Head Cover for cutter Ø 7.9" - 23.6"	Head Cover for cutter Ø 7.9" - 23.6"
0014.3007	Skid for IMC 400 - 600	Skid for IMC 400 - 600	15.8" - 23.6"	4.4
0014.3008	Additional weight for impact milling cutter	Additional weight for impact milling cutter	12 - 24	14.88
14.2215ZS	Pull-rod M22x1.5 x 8"	Pull-rod M22x1.5 x 8"	8 - 24	2.21
14.500K	Impact milling-cutter head 19.7"	Impact milling-cutter head 19.7"	20	37.48
14.500NA	Hub for impact drilling-cutter 19.7"	Hub for impact drilling-cutter 19.7"	20	28.00
14.600K	Impact milling-cutter head 23.6"	Impact milling-cutter head 23.6"	24	41.89
14.600NA	Hub for impact drilling-cutter 23.6"	Hub for impact drilling-cutter 23.6"	24	28.00
14.G	Glide plate cutter 200 - 600	Glide plate cutter 200 - 600		0.55
14.K04	Cam plate 0.16"	Cam plate 0.16"		1.01
