Wire rope and chain scrapers

The Chain scraper enz® is an apparatus which has many uses and is simple in handling and maintenance. Several different pipe diameters can be cleaned with the same tool. Layers of mineral deposits and concrete residues are efficiently removed.

Applications

As preliminary operation before renovation with inliners, coatings or by injections
Complete root removal
Removal of incrustations and deposits
Removal of concrete residues in newly installed sewage pipelines prior to inspection

enz® Chain scraper/Kettenschleuder 10.400R - calcium deposits/Kalkablagerungen

enz® - Chain scraper - roots

enz®│Chain scraper 10 200R│Roots

Chain scraper 10.028 1/4"

	Item number	Item name
	10.028	Chain flail 40 - 100 mm	1/4"	40 - 100	20	3 x M4	3 x M4	40 / 28 x 81	0.90	350

Chain scraper 10.060TR 3/8" - 3/4"

Item number	Item name
10.060ATR	Chain flail Ø 100 mm	3/8"	60 - 200	30	2 x M6	4 x M6	40 x 112	1.40	ok	350
10.060BTR	Chain flail 100 mm	1/2"	60 - 200	30	2 x M6	4 x M6	40 x 112	1.40	ok	350
10.060CTR	Chain flail 100 mm	3/4"	60 - 200	30	2 x M6	4 x M6	40 x 134	1.05	ok	250

Chain scrapers 10.061A/B 1/2" - 3/4"

Item number	Item name
10.061A	Chain flail 60 mm	1/2"	80 - 200	60	3 x M6	3 x M6	60 x 134	1.60	250
10.061B	Chain flail 60 mm	3/4"	80 - 200	60	3 x M6	3 x M6	60 x 134	1.60	250

Chain scraper 10.125TR 1"

Item number	Item name
10.125TR	TurboJet Chain flail Ø125mm							3.00
10.125TR-100	TurboJet Chain flail	1"	100	50	2 x M6	4 x M8	60 x 151	2.50	ok	250
10.125TR-125	TurboJet Chain flail	1"	125	50	2 x M6	4 x M8	60 x 151	2.50	ok	250
10.125TR-150	TurboJet Chain flail	1"	150	50	2 x M6	4 x M8	60 x 151	2.50	ok	250
10.125TR-200	TurboJet Chain flail	1"	200	50	2 x M6	4 x M8	60 x 151	4.00	ok	250
10.125TR-225	TurboJet Chain flail	1"	225	50	2 x M6	4 x M8	60 x 151	2.50	ok	250
10.125TR-250	TurboJet Chain flail	1"	250	50	2 x M6	4 x M8	60 x 151	2.50	ok	250
10.125TR-300	TurboJet Chain flail	1"	300	150	2 x M6	4 x M8	60 x 151	2.50	ok	250

Chain scraper 10.150RL 1"

	Item number	Item name
	10.150RL	Chain flail 80 mm - Ø 150 - 250 mm	1"	150 - 250	100	3 x M8	3 x M10	135 - 235 x 500	13.10	ok	200

Wire rope and chain scrapers sets

Item number		Item name
09.001028	Tool Case small 261x175x77 mm	Tool Case small 261x175x77 mm	1/4"	0.60
10.060ATR-GS	Chain flail 60 - 150 mm	Chain flail 60 - 150 mm	3/8"	2.32
10.060ATR-SET-CH	Chain flail 60 - 150 mm	Chain flail 60 - 150 mm	3/8"	2.90
10.060BTR-GS	Chain flail 60 - 150 mm	Chain flail 60 - 150 mm	1/2"	3.10
10.060BTR-SET-CH	Chain flail 60 - 150 mm	Chain flail 60 - 150 mm	1/2"	2.90
10.060CTR-GS	Chain flail 60 - 150 mm	Chain flail 60 - 150 mm	3/4"	2.30
10.060CTR-SET-CH	Chain flail 60 - 150 mm	Chain flail 60 - 150 mm	3/4"	3.10
10.125TR-100-GS	TurboJet Chain flail Ø125mm	TurboJet Chain flail Ø125mm	1"	5.90
10.125TR-GS	TurboJet Chain flail	TurboJet Chain flail	1"	7.20
10.125TR-SET-CH	TurboJet Chain flail Ø125mm	TurboJet Chain flail Ø125mm	1"	7.60
10.125TR-SET-UK	TurboJet Chain flail Ø125mm	TurboJet Chain flail Ø125mm	1"	7.60
10.125TR-SET100-CH	TurboJet Chain flail Ø125mm	TurboJet Chain flail Ø125mm	1"	7.90

Wire rope and chain scrapers 10.200R/RS

Item number	Item name
10.200R	Chain flail 200 - 400 mm	1"	200 - 400	200	3 x M10	3 x M10	185 - 385 x 560	35.00	ok	200
10.200RS	Chain flail 200 - 400 mm	1"	200 - 400	200	3 x M10	3 x M10	185 - 385 x 560	35.00	ok	200

Wire rope and chain scrapers 10.300R 1"

	Item number	Item name
	10.300R	Chain flail 200 - 500 mm	1"	200 - 500	200	3 x M10	3 x M10	185 - 485 x 560	49.00	ok	200

Wire rope and chain scrapers 10.400R 1"

Item number	Item name
10.400R	Chain flail 400 - 800 mm	1"	400 - 800	300	3 x M10	3 x M10	385 - 785 x 625	52.00	ok	200
10.400RS	Chain flail 400 - 800 mm	1"	400 - 800	300	3 x M10	3 x M10	385 - 785 x 625	47.00	ok	200

Chain scrapers 10.800R 1 1/4"

	Item number	Item name
	10.800R	Chain flail Ø 800 - 1200 mm for recycling water	1 1/4"	800 - 1200	400	3 x M10	6 x M10	560 / 775 x 1640	185.00	ok	200

Accessory 10.028

10.028

	Pipe diameter	Ø 50 mm	Ø 75 mm	Ø 100 mm	Ø per meter
Pin bolt chain Ø 75 mm	Pin bolt chain Ø 75 mm		0010.028075G	0010.028100G	0010.028G
	Link chains Ø 50 mm	0010.028050K	0010.028075K	0010.028100K	0010.028K
Cover with cutter	Cover with cutter	0010.0285M	0010.0285M	0010.0285M
Plastic guide	Plastic guide	0010.0286	0010.0286	0010.0286

Accessories 10.060

10.060ATR

	Pipe diameter	Ø 60 mm	Ø 75 mm	Ø 100 mm	Ø 125 mm	Ø 150 mm	Ø 200 mm	per meter
Set Pin bolt chain with plates Ø 60 mm	Set Pin bolt chain with plates Ø 60 mm	0010.060060G	0010.060075G	0010.060100G	0010.060125G	0010.060150G	0010.060200G	11.G
Set link chains Ø 60 mm	Set link chains Ø 60 mm	0010.040060K	0010.040075K	0010.040100K	0010.040125K	0010.040150K	0010.040200K	0010.040K
	Cover with cutter	0010.0605TRM	0010.0605TRM	0010.0605TRM	0010.0605TRM	0010.0605TRM	0010.0605TRM
Cage for TurboJet 60	Cage for TurboJet 60	0010.0607TR	0010.0607TR	0010.0607TR	0010.0607TR	0010.0607TR	0010.0607TR

Skid Turbojet 60	Skid Turbojet 60			0010.060710TR	0010.060712TR	0010.060715TR	0010.060720TR

Accessoires 10.061A/B

10.061A

	Pipe diameter	Ø 80 mm	Ø 100 mm	Ø 150 mm	Ø 200 mm	per meter
Set chains 4.5 mm - 7 links	Set chains 4.5 mm - 7 links	11.07	11.09	11.11	11.13	11
Bronce-bushing for 10.061A/B	Bronce-bushing for 10.061A/B

Accessories 10.125TR

10.125TR

	Pipe diameter	Ø 125 mm	Ø 150 mm	Ø 200 mm	Ø 225 mm	Ø 250 mm	Ø 300 mm	per meter
Set Pin bolt chain with plates	Set Pin bolt chain with plates	0010.125125G	0010.125150G	0010.125200G	0010.125225G	0010.125250G	0010.125300G	0010.125G
Set link chains	Set link chains	0010.125125K	0010.125150K	0010.125200K	0010.125225K	0010.125250K	0010.125300K	11
Set wire brushs	Set wire brushs		0010.125150SE	0010.125200SE		0010.125250SE
Cover with cutter	Cover with cutter	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR
Cage for 10.125TR	Cage for 10.125TR	0010.1257TR	0010.1257TR	0010.1257TR	0010.1257TR	0010.1257TR	0010.1257TR
Skid	Skid	0010.125712TR	0010.125715TR	0010.125720TR	0010.125722TR	0010.125725TR	0010.125730TR

Accessories 10.150RL

	Item number		Item name
	10.150D-KS150	Diamond crown to 10.150RL	Diamond crown to 10.150RL		2.25

10.150RL

	Pipe diameter	Ø 150 mm	Ø 200 mm	Ø 250 mm	per meter
Set Pin bolt chain	Set Pin bolt chain	0010.150150G	0010.150200G	0010.150250G	0010.150G
Set chains	Set chains	0010.150150K	0010.150200K		11.B
Set Chain plates	Set Chain plates	0010.1508R	0010.1508R	0010.1508R
	Skids Chain Flail 150 - 250	0010.1502R	0010.1502R	0010.1502R
Diamond crown	Diamond crown	0010.150D	0010.200D	0010.250D

Accessories 10.200R/RS & 10.300R

Item number		Item name
0010.200D-HF	Diamond crown	Diamond crown	2.90
10.200D-KS150	Diamond crown to 10.150RL	Diamond crown to 10.150RL	2.90
10.200D-KS200	Diamond crown to KS200-400	Diamond crown to KS200-400	2.90
10.250D-KS150	Diamond crown to 10.150RL	Diamond crown to 10.150RL	7.00
10.250D-KS200	Diamond crown to KS200-400	Diamond crown to KS200-400	7.00
10.300D-KS200	Diamond crown to KS200-400	Diamond crown to KS200-400	7.10

10.200R

	Pipe diameter	Ø 200 mm	Ø 250 mm	Ø 300 mm	Ø 350 mm	Ø 400 mm	Ø 500 mm	per meter
Set Pin bolt chain with plate	Set Pin bolt chain with plate	12.200G	12.250G	12.300G	12.350G	12.401G	12.600G	12.G
Set chains	Set chains	12.03	12.07	12.09	12.11	12.13	12.17	12
Pull part 10.200R/10.400R	Pull part 10.200R/10.400R	0010.2006	0010.2006	0010.2006	0010.2006	0010.2006	0010.2006
Set Chain plates	Set Chain plates	0010.2008R	0010.2008R	0010.2008R	0010.2008R	0010.2008R	0010.2008R



Center head with 4 link chain	Center head with 4 link chain	0010.2004R	0010.2004R	0010.2004R	0010.2004R	0010.2004R
Wire rope head adaption kit	Wire rope head adaption kit	0010.200S	0010.200S	0010.200S	0010.200S	0010.200S
Set of wire rope loop	Set of wire rope loop	12.200S	12.250S	12.300S	12.350S	12.400S
Set of wire rope brush	Set of wire rope brush	12.200SE	12.250SE	12.300SE	12.350SE	12.400SE
Diamond crown	Diamond crown	0010.200D	0010.250D	0010.300D
Skid Front Chain Scraper	Skid Front Chain Scraper	0010.20071R	0010.20071R	0010.20071R	0010.20071R	0010.20071R
Skid back Chain Scraper	Skid back Chain Scraper	0010.20072R	0010.20072R	0010.20072R	0010.20072R	0010.20072R
Cover with cutter	Cover with cutter	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR
Root knife chain flail 10.200RS	Root knife chain flail 10.200RS	0010.2509	0010.2509	0010.2509	0010.2509	0010.2509
Center head with 4 link chain	Center head with 4 link chain	0010.2004R1	0010.2004R1	0010.2004R1	0010.2004R1	0010.2004R1
Skid adapter Ø 500	Skid adapter Ø 500			10.2005R	10.2005R	10.2005R	10.2005R
Head 300R with chain	Head 300R with chain	0010.2005R	0010.2005R	0010.2005R	0010.2005R	0010.2005R	0010.2005R
Head 200RS with chain	Head 200RS with chain	0010.2006R	0010.2006R	0010.2006R	0010.2006R	0010.2006R
Set chains with 3 links and plates	Set chains with 3 links and plates	12.03P	12.07P	12.09P	12.11P	12.13P

Accessories 10.400R

10.400R

	Pipe diameter	Ø 400 mm	Ø 450 mm	Ø 500 mm	Ø 550 mm	Ø 600 mm	Ø 650 mm	Ø 700 mm	Ø 750 mm	Ø 800 mm	per meter
Set Pin bolt chain with plate	Set Pin bolt chain with plate	12.402G	12.450G	12.500G	12.600G	12.600G	12.700G	12.700G	12.800G	12.800G	12.G
Chain (Set 3 x 10cm) for center head of 10.400R	Chain (Set 3 x 10cm) for center head of 10.400R	12.400ZG	12.400ZG	12.400ZG	12.400ZG	12.400ZG	12.400ZG	12.400ZG	12.400ZG	12.400ZG
Set chains	Set chains	12.07	12.09	12.11	12.13		12.17				12
Pull part 10.200R/10.400R	Pull part 10.200R/10.400R	0010.2006	0010.2006	0010.2006	0010.2006	0010.2006	0010.2006	0010.2006	0010.2006	0010.2006



Center head (all Ø)	Center head (all Ø)	0010.4004R	0010.4004R	0010.4004R	0010.4004R	0010.4004R	0010.4004R	0010.4004R	0010.4004R	0010.4004R
Wire rope head	Wire rope head	0010.400S	0010.400S	0010.400S	0010.400S	0010.400S
Wire rope loop (1 set)	Wire rope loop (1 set)	12.250S	12.300S	12.350S	12.400S	12.600S		12.700S
Set of wire rope brush 250 mm	Set of wire rope brush 250 mm	12.250SE	12.300SE	12.350SE	12.400SE
Skids with wheels for egg profile	Skids with wheels for egg profile	10.4008R	10.4008R	10.4008R	10.4008R	10.4008R	10.4008R	10.4008R	10.4008R	10.4008R
Root knife chain scraper	Root knife chain scraper	0010.3804	0010.3804	0010.3804	0010.3804	0010.3804	0010.3804	0010.3804	0010.3804	0010.3804
Cover with cutter	Cover with cutter	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR	0010.1254TR
Set chains with 7 links and plates	Set chains with 7 links and plates	12.07P	12.09P	12.11P		12.15P		12.19P
