Silverline chisel point nozzles 1/8" NPT - 3/4"
| Item number | Item name |
|
|
|
|
|
|
|
|
|
|
|
| 60.012NSL15 |
Pointed nozzle 4 Gsm 1400 Psi |
1/8" NPT | 1 - 2 | 4 | 3 x 0.95 | 4 x 0.50 | 25° | 15° | 0.6 x 1.0 | 0.04 | 5,000 | |
| 60.025NSL15 |
Pointed nozzle 4 Gsm 1400 Psi |
1/4" NPT | 1 - 2 | 4 | 3 x 0.90 | 4 x 0.60 | 25° | 15° | 0.8 x 1.3 | 0.06 | 5,000 | |
| 60.050SL100 |
Pointed nozzle 26.5 Gsm 1400 Psi |
1/2" | 2 - 6 | 26 | 3 x 2.40 | 4 x 1.10 | 25° | 15° | 1.3 x 2.2 | 0.31 | 5,000 | |
| 60.050SL40 |
Pointed nozzle 10.5 Gsm 1400 Psi |
1/2" | 2 - 6 | 11 | 3 x 1.50 | 4 x 0.80 | 25° | 15° | 1.3 x 2.2 | 0.31 | 5,000 | |
| 60.050SL70 |
Pointed nozzle 18.5 Gsm 1400 Psi |
1/2" | 2 - 6 | 18 | 3 x1.80 | 4 x 0.90 | 25° | 15° | 1.3 x 2.2 | 0.31 | 5,000 |
Silverline chisel point nozzles 1/8" NPT - 3/4"
Chisel point nozzles 3/8" NPT - 1 1/4"
| Item number | Item name |
|
|
|
|
|
|
|
|
|
|
|
|
| 60.038N |
Chisel point nozzle |
3/8" NPT | 1.1 - 3.9 | 7.9 | 3 x M4 | 4 x M4 | 20° | 15° | 1 x 1.7 | 0.18 | ok | 5,000 | |
| 60.050 |
Chisel point nozzle |
1/2" | 2 - 6 | 13 | 3 x M6 | 4 x M4 | 25° | 15° | 1.3 x 2.2 | 0.31 | ok | 5,000 | |
| 60.075 |
Chisel point nozzle |
3/4" | 2 - 10 | 26 | 3 x M6 | 4 x M4 | 25° | 15° | 1.5 x 3.2 | 0.71 | ok | 5,000 | |
| 60.100 |
Chisel point nozzle |
1" | 4 - 12 | 40 | 6 x M6 | 4 x M6 | 25° | 15° | 1.9 x 3.5 | 1.21 | ok | 3,600 | |
| 60.100L |
Chisel point nozzle Ø 68 execution long |
1" | 6 - 16 | 53 | 6 x M10 | 4 x M8 | 25° | 15° | 2.7 x 7.4 | 5.95 | ok | 3,600 | |
| 60.100L80 |
Pointed nozzle Ø 80 execution long |
1" | 6 - 20 | 53 | 6 x M10 | 4 x M8 | 10° | 15° | 3.1 x 8.6 | 10.32 | ok | 3,600 | |
| 60.125 |
Chisel point nozzle |
1 1/4" | 6 - 16 | 53 | 6 x M6 | 4 x M6 | 20° | 15° | 2.3 x 3.9 | 17.6 | ok | 3,600 | |
| 60.125L |
Pointed nozzle execution long |
1 1/4" | 8 - 32 | 79 | 6 x M10 | 4 x M8 | 10° | 15° | 3.9 x 10.2 | 18.52 | ok | 3,600 |
Chisel point nozzles 3/8" NPT - 1 1/4"
Chisel point nozzles with centre spire 1/2" - 1 1/4"
| Item number | Item name |
|
|
|
|
|
|
|
|
|
|
|
|
| 61.050 |
Chisel point nozzle with centre spire |
1/2" | 2 - 6 | 13 | 3 x M6 | 3 x M4 | 25° | 15° | 1.3 x 3.2 | 0.32 | ok | 5,000 | |
| 61.075 |
Chisel point nozzle with centre spire |
3/4" | 2 - 10 | 26 | 3 x M6 | 3 x M4 | 25° | 15° | 1.5 x 4.1 | 0.72 | ok | 5,000 | |
| 61.100 |
Chisel point nozzle with centre spire |
1" | 4 - 12 | 40 | 6 x M6 | 3 x M6 | 25° | 15° | 1.9 x 4.9 | 1.24 | ok | 3,600 | |
| 61.100L |
Chisel point nozzle Ø 68 execution long |
1" | 6 - 16 | 53 | 6 x M10 | 3 x M8 | 25° | 15° | 2.7 x 8.7 | 5.96 | ok | 3,600 | |
| 61.100L80 |
Pointed nozzle Ø 80 execution long |
1" | 6 - 20 | 53 | 6 x M10 | 3 x M8 | 10° | 15° | 3.1 x 10.2 | 10.37 | ok | 3,600 | |
| 61.125 |
Chisel point nozzle with centre spire |
1 1/4" | 6 - 16 | 53 | 6 x M6 | 3 x M6 | 20° | 15° | 2.3 x 5.2 | 2.07 | ok | 3,600 | |
| 61.125L |
Pointed nozzle execution long |
1 1/4" | 8 - 32 | 79 | 6 x M10 | 3 x M8 | 10° | 15° | 3.9 x 11.8 | 18.57 | ok | 3,600 |
Chisel point nozzles with centre spire 1/2" - 1 1/4"
Accessory and wearing parts chisel point nozzles
| Item number | Item name |
|
|
|
|||
| 0061.0504 |
Centre spire for Pointed Nozzle 60.050
|
Centre spire for Pointed Nozzle 60.050 |
M4 | 0.2 x 1.0 | 0.22 | ||
| 0061.1004 |
Centre spire for Pointed Nozzle 60.100
|
Centre spire for Pointed Nozzle 60.100 |
M6 | 0.4 x 1.3 | 0.22 | ||
| 0061.1254 |
Centre spire for Pointed Nozzle 60.100L80,
|
Centre spire for Pointed Nozzle 60.100L80, |
M8 | 0.4 x 2.0 | 0.22 |
Accessory and wearing parts chisel point nozzles
